UNIDRIVE HS30
0 – 3,000 Hz Open Loop
0.25 kW – 7.5 kW (0.33 hp – 10 hp)
200 V / 400 V
Unidrive HS30 is designed for applications that require cost effective integration into safety systems and incorporates dual Safe Torque Off and advanced Rotor Flux Control (RFC-A) of open loop induction motors.
Specifications:
Key data
- Heavy Duty rating: 0.25 – 132 kW (0.33 – 179 hp)
- Supply phases:
- Size 1 to 4: 110 V drives – 1 phase, 230 and 400 V drives – 1 or 3 phase
- Size 5 upwards: 3 phase
Standard features
Machine safety:
- 2 x Safe Torque Off terminals
Keypad:
- Fixed LED
Option slots:
- 1 (Size 2 and above)
Parameter cloning via:
- PC tools
- SD card with AI-Smart Back Up
- AI-Smart Adaptor
| VOLTAGE RATINGS | |
| 100 V (100 V – 120 V ± 10%) | ✓ |
| 200 V (200 V – 240 V ± 10%) | ✓ |
| 400 V (380 V – 480 V ± 10%) | ✓ |
| 575 V (500 V – 575 V ± 10%) | ✓ |
| 690 V (500 V – 690 V ± 10%) |
| CONTROL MODE | |
| Open loop vector or V/Hz induction motor control | ✓ |
| Open loop Rotor Flux Control for induction motors (RFC-A) | ✓ |
| Open loop permanent magnet motor control (RFC-S) | |
| Closed loop Rotor Flux Control for induction motors (RFC-A) | |
| Closed loop permanent magnet motor control (RFC-S) | |
| Active Front End (AFE) power quality convertor |
| FRAME SIZE | DIMENSIONS (H X W X D) | WEIGHT | ||
|---|---|---|---|---|
| mm | in | kg | lb | |
| 1 | 160 x 75 x 130DIN rail mounting*137 x 75 x 130 | 6.3 x 3.0 x 5.1 DIN rail mounting* 5.4 x 3.0 x 5.1 | 0.75 | 1.65 |
| 2 | 205 x 75 x 150 DIN rail mounting* 180 x 75 x 150 | 8.1 x 3.0 x 5.9DIN rail mounting*7.1 x 3.0 x 5.9 | 1.0 | 2.2 |
| 3 | 226 x 90 x 160 | 8.9 x 3.5 x 6.3 | 1.5 | 3.3 |
| 4 | 277 x 115 x 175 | 10.9 x 4.5 x 6.9 | 3.13 | 6.9 |
*Additional fixings required to maximize security
Advantages
Conform to safety standards, maximize uptime and reduce costs by integrating directly with safety systems
- HS30 has integrated dual STO inputs for SIL3, PLe conformity, eliminating the need for external safety components
Improve throughput with advanced open-loop motor control algorithms
- Rotor Flux Control (RFC-A) gives maximum stability and control of induction motors at all powers.
- 180% motor overload suitable for heavy industrial machinery applications
Flexible system integration with SI communications options
- HS30’s SI interface enables integration with a wide range of available industry standard fieldbuses and I/O
Install and configure quickly and easily
- Simple fixed LED keypad
- Useful parameter guide located on the front of the drive
- Use Unidrive M Connect or an SD card with the AI-Backup adaptor to clone and transfer parameter sets
- DIN rail mounting is supported below 1.5 kW
