UNIDRIVE M700
0.75 kW – 2.8 MW (1.0 – 4,200 hp)
200 V / 400 V / 575 V / 690 V
The bread and butter of Control Techniques is honing our unique motor control algorithms, taking pride in our craft as any good craftsman would. This ensures that our Unidrive M series drives offer the highest control stability and bandwidth for every industrial motor type.
Unidrive M enables maximum machine throughput in every application and with every motor, from standard AC induction motors to dynamic linear motors and from energy saving hybrid permanent-magnet motors to high performance servo motors.
Specifications:
Key data
- Heavy Duty rating: 0.75 kW – 2.8 MW (1.0 – 4,200 hp)
- Supply phases: 3 phase
Standard features
Intelligence:
- Onboard PLC
- Advanced Motion Controller
Onboard comms:
- M700 & M702 – Ethernet
- M701 – RS485
Feedback:
- 2 x Encoder inputs
- 1 x Simulated encoder output
Machine safety:
- M700 & M701 – 1 x Safe Torque Off (STO) terminal
- M702 – 2 x STO terminals
- SIL3/PLe compliant
Keypad:
- No keypad as standard
Option slots:
- 3
Parameter cloning via:
- PC tools
- Smartcard
- SD card
| VOLTAGE RATINGS | |
| 100 V (100 V – 120 V ± 10%) | |
| 200 V (200 V – 240 V ± 10%) | ✓ |
| 400 V (380 V – 480 V ± 10%) | ✓ |
| 575 V (500 V – 575 V ± 10%) | ✓ |
| 690 V (500 V – 690 V ± 10%) | ✓ |
| CONTROL MODE | |
| Open loop vector or V/Hz induction motor control | ✓ |
| Open loop Rotor Flux Control for induction motors (RFC-A) | ✓ |
| Open loop permanent magnet motor control (RFC-S) | ✓ |
| Closed loop Rotor Flux Control for induction motors (RFC-A) | ✓ |
| Closed loop permanent magnet motor control (RFC-S) | ✓ |
| Active Front End (AFE) power quality convertor | ✓ |
SINGLE DRIVES:
| FRAME SIZE | DIMENSIONS (H X W X D) | WEIGHT | ||
| mm | in | kg | lb | |
| 3 | 382 x 83 x 200 | 15.0 x 3.3 x 7.9 | 4.5 Max | 9.9 Max |
| 4 | 391 x 124 x 200 | 15.4 x 4.9 x 7.9 | 6.5 | 14.3 |
| 5 | 391 x 143 x 200 | 15.4 x 5.6 x 7.6 | 7.4 | 16.3 |
| 6 | 391 x 210 x 227 | 15.4 x 8.3 x 8.9 | 14 | 30.9 |
| 7 | 557 x 270 x 280 | 21.9 x 10.6 x 11.0 | 28 | 61.7 |
| 8 | 803 x 310 x 290 | 31.6 x 12.2 x 11.4 | 52 | 114.6 |
| 9A | 1108 x 310 x 290 | 43.6 x 12.2 x 11.4 | 66.5 | 146.6 |
| 9E | 1069 x 310 x 288 | 42.1 x 12.2 x 11.3 | 46 | 101.4 |
| 10E | 1069 x 310 x 288 | 42.1 x 12.2 x 11.3 | 46 | 101.4 |
| 11E | 1410 x 310 x 310 | 55.5 x 12.2 x 12.2 | 63 | 138.9 |
All dimensions include mounting brackets
MODULAR DRIVES:
| FRAME SIZE | DIMENSIONS (H X W X D) | |
|---|---|---|
| mm | in | |
| INVERTER& RECTIFIER | ||
| 9A | 1108 x 310 x 290 | 43.62 x 12.21 x 11.4 |
| 9E | 9T | 1069 x 310 x 290 | 42.1 x 12.21 x 11.4 |
| 10E | 10T | 1069 x 310 x 290 | 42.1 x 12.21 x 11.4 |
| 11E | 11T | 1242 x 310 x 312 | 48.9 x 12.2 x 12.3 |
| INVERTER | ||
| 9D | 773 x 310 x 290 | 30.4 x 12.2 x 11.4 |
| 10D | 773 x 310 x 290 | 30.4 x 12.2 x 11.4 |
| 11D | 863 x 310 x 290 | 34 x 12.2 x 12.3 |
| RECTIFIER | ||
| 10A | 6 pulse355 x 310 x 290 | 6 pulse13.9 x 12.2 x 11.4 |
| 11A | 11T | 6 pulse 415x 310 x 290 12 pulse 415x 310 x 290 | 6 pulse 16.3 x 12.2 x 11.4 12 pulse 16.3 x 12.2 x 11.4 |
All dimensions include mounting brackets
Advantages
Maximize throughput with superior motor control
- High bandwidth motor control algorithm for closed-loop induction, permanent magnet and servo motors – 3000 Hz current loop bandwidth and 250 Hz speed loop bandwidth
- Flexible speed and position feedback interface supports a wide range of feedback technologies from robust resolvers to high resolution encoders
- Up to three encoder channels simultaneously e.g. 1 feedback encoder, 1 reference encoder and 1 simulated output
- MCi modules can eliminate the need for external PLCs and motion controllers
- Simulated encoder output can provide position reference for CAMs, digital lock and electronic gearbox applications
Optimize system performance with onboard Advanced Motor Controller
- M700 incorporates an Advanced Motion Controller capable of controlling 1.5 axes. The motion functions are carried out ‘on the drive’ so that system performance is maximized
Design flexible centralized and decentralized control systems
- MCi modules can be added to execute larger programs for advanced system control capability
- Onboard PLC for logic programs
- Machine Control Studio is an industry standard IEC61131-3 programming environment for efficient system design and configuration
- Integrated dual port Ethernet switch provides simple connectivity using standard connections
- Onboard real-time Ethernet (IEEE 1588 V2) uses RTMoE (Real Time Motion over Ethernet) to provide fast communication and accurate axis synchronization
- Three System Integration ports are available to fit additional fieldbus, position feedback and I/O options
Conform to safety standards, maximize uptime and reduce costs by integrating directly with safety systems
- M700 has an integrated Safe Torque Off (STO) input and can accommodate an SI-Safety module for safe motion functions
